The resistance for your mat or cable is calculated on the length of the heater. Shortening the heater would increase the resistance and thereby the temperature. The cable is expected to operate fine at slightly higher temperatures for a time, but it may put undue strain on the end-splice, which may then trip and eventually fail.
Why does my thermostat trip every time it reaches the same temperature? Read More »
When applied, you will select a number and this percentage represents the number of minutes the heat will be on out of every 10 minute cycle. For example, if you select 60%, the heat will be on for 6 minutes, followed by 4 minutes of the system being off. Then, after the 4 minutes, it will activate again for 6 and so on. This will continue until your programmed heating period ends or until you manually turn off the heat.
Why does my thermostat read a percentage (Regulator Mode)? Read More »
This message will occur if a ground fault is detected. Click “Read More” for details.
If wire spacing and floor height isn’t consistent, your floor may not heat evenly. Click “Read More” for details.
Why does my floor heat unevenly? Read More »
Your floor can reach higher temperatures in some areas where furniture, area rugs, dog beds or other fixtures are trapping the heat. Click “Read More” for details.
Why does my floor get warmer in some spots? Read More »
Click “Read More” or more information about installing on a concrete slab.
What to do when Installing FOIL on a Concrete Slab ? Read More »
When setting up a large installation and connecting two or more thermostats as Master and Relays, all devices MUST have a floor sensor hooked up. Click “Read More” for details.
Master/Relay (relay reading ER1) Read More »
We have outlined some important reminders to ensure proper functioning of your Foil Floor Heating System. Click “Read More” for details.
Installing the FOIL System Under Carpet Read More »
You will want to review these electric heating mat system installation tips before you begin your electric floor heating installation project. Tips such as how the factory joint is positioned to how to extend the unheated lead. Click “Read More” for details.
Installation Tips for the DWM Heating Mat System Read More »
While you must NEVER cut the wire, the mat system is designed to allow you to separate the wire from the mesh. The unusable mesh can be cut away from the mat. Now that you have freed the wire, you can install the wire around the area using hot-glue or tape to secure the cable away from any drains or screw-mounts.
How to install a floor heating mat around a drain in a shower ? Read More »
